Details

Specifications:

- Lead Screw dia. : 17mm Pitch : 1mm : Thread Length: 205mm

- Lead screw and its nut are optically aligned maintain constancy for the pitch.

- Mirror mount are kinematics type have in orthogonal tilt arrangement in x & y means of fine there added screw.

- Square mirror holders (fitted with mirror mount) are able to hold the mirrors, Mirror dia.: 0 mm thickness. : 15mm.

- Interferometer is provided by three scales.

- A scale (0-150mm graduated in mm) is attached with the bed of interferometer.

- Graduated small drum (0-100Div.) may be peeped through glass window provided with the head of the interferometer. One division of graduated disc =0.01mm.

- A graduated slow motion small drum (graduation 0-100Div.) is fitted on Right hand side of the interferometer. One division  of slow motion drum =.0001mm.

- Least count of interferometer: 10-4 mm.

Specifications of optically component :

Optical Beam splitter (42x32x8.5mm): slightly cited. Coating Material: Al+Sio2: R/T ratio: 50/50 + 50% Parallelism < 3 arc second.

Note: Infect beam splitter (before coating) and compensating plate are carved from the same optically worked glass plate having thickness: 8.5mm. : Surface Flatness. l/10 and parallel is in between two faces <3 arc second for optically proved.

Mirrors (Front surface coated Dia. : 30mm, thickness 15mm.

Surface flatness of coated face: l/10 and other faces optically ground.

Mirror reflectivity > 95%.



Weights = 15 kg approximate including stand & packing

Dimensions = 17½” x 16” x 10”

Stand Box = 14” x 13” x 10”

-

Michelson Interferometer                            Catalog No. 101030
